Česle na odpadní vodu

Step Screen Type PROSTEP

Technical Data of Step Screen type PROSTEP

 | Max. Flow (m3/h)  | 1,000
| Bar Spacing (mm)  | 2 to 6
| Width (mm)  | 300 to 2,000
| Max. Depth under Installation Plane (mm)  | 2,000
| Discharge Side  | Downstream
| Slope  | 45°
| Material  | 304L or 316L

See Product Page

Bar Screen Type SI350

Technical Data of Bar Screen Type SI350

 | Max. Flow (m3/h)  | 50
| Bar Spacing (mm)  | 6, 10, 15, 20
| Width (mm)  | 350
| Max. Depth under Installation Plane (mm)  | 400 to 900
| Discharge Side  | Downstream
| Slope  | 15°
| Material  | 304L or 316L

See Product Page

Bar Screen Type SG400

Technical Data of Bar Screen type SG400

 | Max. Flow (m3/h)  | 120
| Bar Spacing (mm)  | 3 to 30
| Width (mm)  | 400
| Max. Depth under Installation Plane (mm)  | 5,500
| Discharge Side  | Upstream
| Slope  | 0°
| Material  | 304L or 316L

See Product Page

Bar Screen Type NG

Technical Data of Bar Screen type NG

 | Max. Flow (m3/h)  | 6,000
| Bar Spacing (mm)  | 3 to 60
| Width (mm)  | 450 to 2,000
| Max. Depth under Installation Plane (mm)  | 17,000
| Discharge Side  | Upstream
| Slope  | 0°
| Material  | 304L or 316L

See Product Page

Bar Screen Type XG

Technical Data of Bar Screen type XG

 | Max. Flow (m3/h)  | 20,000
| Bar Spacing (mm)  | 3 to 30
| Width (mm)  | 450 to 2,000
| Max. Depth under Installation Plane (mm)  | 17,000
| Discharge Side  | Downstream
| Slope  | 0°
| Material  | 304L or 316L

See Product Page

Bar Screen Type NI

Technical Data of Bar Screen type NI

 | Max. Flow (m3/h)  | 25,000
| Bar Spacing (mm)  | 10 to 100
| Width (mm)  | 800 à 3,000
| Max. Depth under Installation Plane (mm)  | 12,000
| Discharge Side  | Downstream
| Slope  | 15°
| Material  | 304L or 316L

See Product Page
